| System parameters | ||
|---|---|---|
| System pressure | 50 | bar |
| System flow | 30 | L/min |
| Motor parameters | ||
| Power | 3.75 | kw |
| Number of revolutions | 1450 | r/min |
| Voltage | 380 | v |
| Frequency | 50 | Hz |
| Fuel tank parameters | ||
| Volume | 150 | L |
| Material | Q235 | |
| Surface treatment | Spray | |
| Feature | |
|---|---|
| 1. | The imported variable vane pump is used together with the inner shaft motor and air cooling, which greatly reduces the heat generation of the system and the installation space |
| 2. | Imported SSAN reversing valve is adopted, which is convenient for operation and use, and improves production efficiency |
| 3. | Using laser cutting and bending technology to ensure the strength and beauty of the equipment |
| Application Industry application | |
|---|---|
| 1. | Multi-axis drilling machine |
| 2. | Fixture |
| 3. | Machining Center |
