| System parameters | ||
|---|---|---|
| System pressure | 210 | bar |
| System flow | 30*2 | L/min |
| Motor parameters | ||
| Power | 5.5*2 | kw |
| Number of revolutions | 1450 | r/min |
| Voltage | 380 | v |
| Frequency | 50 | Hz |
| Fuel tank parameters | ||
| Volume | 500 | L |
| Material | Q235 | |
| Surface treatment | Spray | |
| Feature | |
|---|---|
| 1. | The imported vane pump is used together with the oil return water cooler, which greatly reduces the heat generation of the system |
| 2. | The motor adopts vertical installation and threaded cartridge valve, which is convenient for operation and use and improves production efficiency |
| 3. | Using laser cutting and bending technology to ensure the strength and beauty of the equipment |
| Application Industry application | |
|---|---|
| 1. | Woodworking machinery and equipment |
| 2. | Automation equipment |
| 3. | Non-standard hydraulic machinery |
