| System parameters | ||
|---|---|---|
| System pressure | 130 | bar |
| System flow | 50 | L/min |
| Motor parameters | ||
| Power | 11 | kw |
| Number of revolutions | 1450 | r/min |
| Voltage | 380 | v |
| Frequency | 50 | Hz |
| Fuel tank parameters | ||
| Volume | 400 | L |
| Material | Q235 | |
| Surface treatment | Spray | |
| Feature | |
|---|---|
| 1. | Imported variable piston pump is used in conjunction with the circuit of Shangyan Company, which greatly reduces the heat generation of the system |
| 2. | Imported proportional reversing valve and imported synchronous motor are used to realize multi-cylinder synchronization and improve production efficiency and precision |
| 3. | Using laser cutting and bending technology to ensure the strength and beauty of the equipment |
| Application Industry application | |
|---|---|
| 1. | Automated assembly line |
| 2. | Woodworking equipment |
| 3. | Special machinery |
