| 系統參數 | ||
|---|---|---|
| 系統壓力 | 120 | bar |
| 系統流量 | 15 | L/min |
| 電機參數 | ||
| 功率 | 2.2 | kw |
| 轉數 | 1450 | r/min |
| 電壓 | 380 | v |
| 頻率 | 50 | Hz |
| 油箱參數 | ||
| 容積 | 120 | L |
| 材料 | Q235 | |
| 表面處理 | 噴塑 | |
| Feature | |
|---|---|
| 1. | The use of low-noise gear pumps in conjunction with accumulators greatly reduces the noise of the system |
| 2. | The system uses an accumulator and unloading circuit to work together, which greatly reduces the energy consumption of the system and reduces the heat generation of the system |
| 3. | The vertical installation of the motor is adopted, which effectively saves the installation space |
| Application Industry application | |
|---|---|
| 1. | Electroplating equipment |
| 2. | Automated machinery |
| 3. | Professional equipment |
